An HVLS fan is a high-volume, low-speed ceiling fan greater than seven feet in diameter. Its large size stirs up and moves enormous amounts of air in all directions. The increased air circulation replaces hot, humid air with drier air.
Benefits
-
More comfortable work environment -
Heightened energy efficiency
-
Better air circulation -
Minimal noise
Workplace safety improves with HVLS fans. Designed to hang from the ceiling, they eliminate trip dangers associated with corded pedestal-mounted or wheeled fans. The air circulation from HVLS fans curbs ground moisture buildup, reducing slip hazards while improving ventilation.
HVLS Fan Models
- Big Industrial HVLS Fan
- Model DX 7.3
- Size 24FT
- No of Blades6
- Motor 1.5 KW / 2HP
- Max Speed: 62 RPM
- Max Air Volume 14,800 m3/min
- Fit for Installation Height(M): 8 ~ 20
- Net Weight 106 Kg
- Noise Level (dB) <= 38
- Big HVLS Fan
- Model DX 7.3 G
- Size 24FT
- No of Blades 6
- Motor 1.8 KW / 2.4HP
- Max Speed 58 RPM
- Max Air Volume 16,300 m3/min
- Fit for Installation Height(M) 8 ~ 30V
- Net Weight 106 Kg
- Noise Level (dB) <= 38
- Big HVLS Fan
- Model DX 6.1
- Size 20FT
- No of Blades6
- Motor 1 KW / 1.35HP
- Max Speed: 65 RPM
- Max Air Volume 12,900 m3/min
- Fit for Installation Height(M): 6 ~ 15
- Net Weight 94 Kg
- Noise Level (dB) <= 38
- Big HVLS Fan
- Model DX 5.0
- Size 16FT
- No of Blades6
- Motor 0.75 KW / 1HP
- Max Speed: 80 RPM
- Max Air Volume 11,500 m3/min
- Fit for Installation Height(M): 5 ~ 11
- Net Weight 68 Kg
- Noise Level (dB) <= 38
- HVLS Industrial Ceiling Fan
- Model DX 5.0D
- Size 16FT
- No of Blades 5
- Motor 0.5 KW / 0.7HP
- Max Speed 90 RPM
- Max Air Volume 9,700 m3/min
- Fit for Installation Height(M) 4 ~ 9
- Net Weight 60 Kg
- Noise Level (dB) <= 38
- High Volume Low Speed Fan
- Model DX 3.6
- Size 12FT
- No of Blades5
- Motor 0.3 KW / 0.4HP
- Max Speed: 95 RPM
- Max Air Volume 6,560 m3/min
- Fit for Installation Height(M): 4 ~ 8
- Net Weight 42 Kg
- Noise Level (dB) <= 38
- Small HVLS Fan
- Model DX 2.4
- Size 8FT
- No of Blades5
- Motor 0.3 KW / 0.4HP
- Max Speed: 120 RPM
- Max Air Volume 4,550 m3/min
- Fit for Installation Height(M): 4 ~ 8
- Net Weight 34 Kg
- Noise Level (dB) <= 38
- Small HVLS Ceiling Fan
- Model DX 3.0
- Size 10FT
- No of Blades5
- Motor 0.3 KW / 0.4HP
- Max Speed: 110 RPM
- Max Air Volume 5,530 m3/min
- Fit for Installation Height(M): 4 ~ 8
- Net Weight 38 Kg
- Noise Level (dB) <= 38
- Small Industrial HVLS Fan
- Model DX 5.5
- Size 18FT
- No of Blades6
- Motor 0.75 KW / 1HP
- Max Speed: 70 RPM
- Max Air Volume 12,200 m3/min
- Fit for Installation Height(M): 5 ~ 11
- Net Weight 72 Kg
- Noise Level (dB) <= 38
Features
Saves huge cost by power saving
Direct Drive Servo Motor
Highest Efficiency, Less Power Consumption
No Maintenance due to simple design
Made with rare earth Neodymium Magnets. It has 20X better life than normal magnets
